Produktbeskrivning

The high-brightness ZU2200 professional laser projector fills a need for high-end installations, including the entertainment, exhibition, and digital signage markets. Part of Optoma's Ultra Bright Series, this projector offers incredibly high brightness of 22000 lumens as well as extreme flexibility with eight interchangeable lenses to meet the needs of even the most complex installations. As part of the Optoma DuraCore laser line up, the Ultra Bright Series high-performance projectors feature 4K HDR compatibility, pure engine video processing and color matching to produce visually striking, lifelike images with exceptional detail and high-color accuracy. Additionally, the ZU2200 achieves superior color rendition through MultiColor Laser (MCL) technology. Strong reliability is at the core of the Ultra Bright Series projectors, with 24/7 operation capabilities, up to 30000 hours of laser lifetime, and an IP5X rating for optimal and dependable performance, even under more extreme conditions up to 122 degrees Fahrenheit / 50 degrees Celsius. With a robust metal chassis and modular design for easier maintenance, a multitude of connectivity options, and failsafe redundancy mode for instant source switching, the Ultra Bright Series projectors offer a solution for intricate installations, including multi-projector and dome projection applications.



Egenskaper

Redundant input with fast switching
The unique signal input detection function provides instant source switching in the event of the failure of the signal source device. This feature ensures an image never fails to display in mission critical installations such as control rooms, live events or other similar scenarios.

Passive 3D compatibility
Passive 3D is available on single-chip DLP laser phosphor projectors. Thanks to the high-efficiency light output, these models enable effective 3D solutions for operators to reduce total cost of ownership.

Metal chassis with modular design
The modular metal chassis panels and quick-release screws make routine maintenance easier than ever before.

Wide temperature operating range
Suitable for various operating environments, the robust and efficient cooling design enable the projectors to withstand an ambient operating temperature range of 0~50°C.

DuraCore
Longer lifetime is achieved using Optoma's DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust-resistant design.

HDR-compatible
Capable of receiving and displaying HDR meta data, Optoma HDR-compatible projectors allow you to see far more detail and texture. Objects look more solid and lifelike and the extra detail creates a greater sense of depth. It's like looking through a window.

Extreme Black
Extreme Black enables the laser diodes to completely turn off when a full black image frame is detected. This feature is perfect for situations where a total image blackout is required.

HDBaseT
Uncompromising, uncompressed Full HD video, audio, network and control commands all delivered on a single CAT-type cable capable up to 100 meters / 328 feet without signal loss makes installation hassle-free. HDBaseT simplifies cabling requirements and reduces installation complexity saving both time and reducing costs.

Amazing color
Optoma projectors provide reliable color performance suitable for any content and environment. From accurate sRGB colors for lifelike images to vibrant punchy presentations. Optoma has a display mode to specific meet your needs. Perfect for a range of graphic and video presentations.

Color Management System (CMS)
Display accurate lifelike colors to best match your viewing environment. This unique feature provides you with the flexibility to fine-tune the color settings of your projector for optimal precision.

Constant power
Allows users to set the power levels to meet individual installation requirements. Power levels can be managed to obtain the brightest picture or longest light source life - or anywhere in between.

Constant brightness
Advanced light sensing technology allows the setting of brightness levels that will remain unchanged over time. Ideal for ensuring constant brightness for fine tune installations.

True AV mute
True AV mute enables the light source of the projector to be instantly switched off and on at the press of a button. Unlike standard AV mute functionality no light is emitted from the projector, this gives 100% blackout on screen.

Full lens shift
Full lens shift makes installation simple and hassle-free, offering the flexibility to move the projected image vertically or horizontally, as well as adjusting the screen size without the need to move or reposition the projector.

Picture-by-picture and picture-in-picture
Signals can be delivered simultaneously via the HDMI and DVI ports, for a PbP or PiP display from two digital sources - perfect for videoconferencing and other collaborative applications.

360° projection
With 360° projection, images can be displayed in any orientation, giving you the freedom and versatility to install this projector in the desired location.

Portrait projection
Ideal for digital signage applications you can rotate your projector 90 degrees to project a portrait image.

IP5X dust-resistant optical engine
Independently tested and certified to IEC standard 60529 with an IP5X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures durability; paramount for 24/7 maintenance-free operation in challenging environments.

RS232
Optoma projectors come with an extensive set of RS232 commands making it simple and easy to manage using any control system.

AMX compatible
Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.

PJLink
PJLink protocol is incorporated into the projector allowing for easy installation with PJLink compatible control systems.

Full 3D
Optoma projectors can display true 3D content from almost any 3D source, including 3D compatible graphics cards, 3D broadcasting and media servers.

Multicolor Laser
Innovative Multicolor Laser (MCL) technology adds a second red laser to the common blue laser. This results in greatly improved color performance.



Teknisk specifikation

Typ av enhet	DLP-projektor
3D-kapabel	Ja
Nätverk	Ethernet

Ljusstyrka	22000 lumen
Kontrastförhållande	2000000:1 (dynamisk)
Upplösning	WUXGA - WUXGA (1920 x 1200) (okomprimerat)/ 4K (storleksändrad)
Ursprungligt visningsformat	16:10
Typ av lampa	Laser
Lamplivslängd	Upp till 30000 timme/timmar
OSD-språk	Ungerska, engelska, tyska, franska, italienska, norska, portugisiska, Polish, spanska, holländska, japanska
Egenskaper	Bild i bild, Kantmixer, bild för bild, stöd för visningsformatet 16:9, PJlink, Crestron RoomView, 360 graders projektion, automatfokus, Dust Resistant Design, ExtremeBlack-läge, High Dynamic Range (HDR), Extron Control System, AMX Control System, DuraCore, Amazing Color, 24/7-användning, Colour Management System (CMS), porträttskydd, Constant Brightness Mode, Multicolor Laser (MCL) technology, AV-dämpning, built-in redundancy mode, auto color uniformity

Typ	Ingen lins

Videogränssnitt	VGA, HDMI, DisplayPort, DVI, 3G-SDI, HDBaseT

Gränssnitt

1 x seriell RS-232-inmatning - 9 pin D-Sub (DB-9) 1 x seriell RS-232-utmatning - 9 pin D-Sub (DB-9) 1 x 3D-synk in 1 x 3D-synkroniserad utmatning 1 x fjärrkontrollingång - minitelefon 3,5 mm 1 x fjärrkontrollutgång - minitelefon 3,5 mm 1 x HDBaseT 1 x DisplayPort - 20-stifts DisplayPort 2 x HDMI-ingång - 19-stifts HDMI typ A 1 x HDMI-utgång - 19-stifts HDMI typ A 1 x VGA - 15 pin HD D-Sub (HD-15) 1 x DVI-digital 1 x 3G-SDI-inmatning 1 x 3G-SDI-utmatning 1 x nätverk - RJ-45 1 x USB (hantering) 1 x 12V programmerbar avtryckare - minitelefon 3,5 mm

Inkluderade tillbehör	Fjärrkontroll till bakgrundsbelysningen
Standarder som följs	IEC 60529 IP5X

Strömkälla	Växelström
Nätspänning	AC 100-240 V (50/60 Hz)
Energiförbrukning vid drift	1200 Watt
Strömkonsumtionsställ med	0.5 Watt

Bredd	65 cm
Djup	68.2 cm
Höjd	30.086 cm
Vikt	54 kg

Emballagets vikt	66.5 kg

Min temperatur vid drift	0 °C
Max temperatur vid drift	50 °C
Luftfuktighet vid drift	10 - 85% RH (non-condensing)
Ljudnivå	38 dB
