Produktbeskrivning

The IFR series' advanced design provides flexibility for any indoor retail or other business environment. With portrait and landscape orientation options, content can be displayed to meet the preferred layout for any store location. LED HDR leverages advanced refinement technologies for true-to-life picture presentation. Dynamic Peaking and Inverse Tone Mapping enhance content to optimum peak brightness levels with improved contrast and without shine, and in-depth Color Mapping ensures an accurate expression of colors.



Egenskaper

Easier installation
The IFR series' design features larger screen size and is lighter than previous models. This means easier installation since fewer cabinets are needed for the display and fewer frame kits are required to mount the display to a wall.

Flexible design
The IFR series' advanced design provides flexibility for any indoor retail or other business environment. With portrait and landscape orientation options, content can be displayed to meet the preferred layout for any store location.

Clearly refined visuals
LED HDR leverages advanced refinement technologies for true-to-life picture presentation. Dynamic Peaking and Inverse Tone Mapping enhance content to optimum peak brightness levels with improved contrast and without shine, and in-depth Color Mapping ensures an accurate expression of colors.

Accurate color in low-brightness arena
Conventional LED displays struggle to present red, green, and blue color hues accurately in low grayscale settings. The IFR series overcomes these challenges through a unique algorithm that maintains R/G/B gradation and delivers precise, detail-rich hues in low-brightness indoor environments.

Fine-tuned uniformity
Rigorous factory calibration and real-time DSLR camera sub-pixel calibration fine-tune all sub-pixels for uniform brightness and color chromaticity.



Teknisk specifikation

Typ av produkt	LED display unit
Kommersiell användning	Ja - digital skyltning
Serie	IFR Series
HDR-förberedd	Ja
HDR-format	HDR10+
HDR-teknologi	LED HDR, Multi-link HDR
TV-tuner	Ingen mottagare
TV-mottagaravkänning	Nej
Design	Flexibel design
Dimensioner	Visningsenhet
Bredd	96 cm
Djup	7.95 cm
Höjd	54 cm
Vikt	12.4 kg

Rampris och förhöjningsteknologi	6 480 Hz uppdateringsfrekvens
Färgtemperatur	2800 - 10000K
Bildkontrastförhållande	8000:1
Ljusstyrka	1000 cd/m²
Bildvinkel	160 grader
Bildvinkel (vertikal)	160 grader
Egenskaper	16-bitars färgbehandling

Pixelavstånd	2.5 mm
Pixelkonfiguration	1 röd, 1 grön, 1 blå
LED-typ	SMD
Upplösning	384 x 216
LED-livstid	100.000 hours
Hantering	Framsida
Modulkonfiguration (per skåp)	4x3

Standarder som följs	EMC Class A, IP20, Safety 60950-1, Safety 62368-1

Nätdel	Nätaggregat
Inspänning	AC 100-240 V (50/60 Hz)
Strömförbrukning för videoväggens visningsenhet (max)	260 W
Strömförbrukning för videoväggens visningsenhet (normal)	87 W
Strömförbrukning för videovägg (max)	502 W/m²
Strömförbrukning för videovägg (normal)	168 W/m²
Funktioner	Power Redundancy

Service och support	Begränsad garanti - 3 år

Bredd (brutto)	111.9 cm
Djup (brutto)	20.6 cm
Höjd (brutto)	69.9 cm
Vikt (brutto)	18.1 kg

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	10 - 80% RH
