Produktbeskrivning

The XS630 stands out with its specialized 1D laser scanning engine, delivering superior performance in environments where 1D barcodes are often damaged, worn, or difficult to read.

Based on the Socket Mobile XtremeScan Mag platform, the XS630 is designed for BYOD (Bring Your Own Device) operations and seamless integration with any mobile device. It offers an optimal solution to enhance efficiency and convenience in mobile workforces. Featuring a secure magnetic attachment system, workers can easily attach and detach their personal mobile devices throughout the day. This flexibility empowers users to switch between tasks such as navigation, photos, and communication while adding high-performance 1D barcode scanning when needed.

With its innovative BYOD design and rugged durability, the XS630 is ideal for modern delivery and inventory operations, ensuring tasks are completed efficiently without requiring multiple devices.

Featuring a streamlined case format, the XS630 offers a compact, easy-to-handle design for comfortable use over long shifts. Its fast, precise 1D laser scanning delivers effortless data capture, and the secure magnetic attachment system allows for quick access when scanning is required. With extended battery life, military-grade durability to withstand drops and harsh conditions, and intuitive LED indicators, the XS630 simplifies scanning tasks while maintaining performance in any work environment.

Equipped with Bluetooth connectivity and a strong metal plate attachment system, the XS630 ensures optimal compatibility with any mobile device and reliable integration with iOS and Android business applications.



Viktiga egenskaper

Socket Mobile XtremeScan Mag XS630. Type: Handheld bar code reader, Scanner type: 1D, Sensor type: LED. Connectivity technology: Wireless, Standard interfaces: Bluetooth, Wireless range: 10 m. Product colour: Black, Green, Housing material: Plastic, Glass, International Protection (IP) code: IP67. Power source type: Battery, Battery technology: Lithium-Ion (Li-Ion), Charging port type: USB Type-C. Width: 91 mm, Depth: 91 mm, Height: 193.1 mm



Teknisk specifikation

Type	Handheld bar code reader
Scanner type	1D
2D (matrix & stacked) barcodes supported	Not supported
Sensor type	LED
Linear (1D) barcodes supported	Codabar,Code 128,Code 93,Code 39,EAN-8,EAN-13,JAN-13,JAN-8,GS1 DataBar Expanded,GS1 DataBar Omnidirectional,GS1 Databar Limited,Interleaved 2 of 5,ISBT 128,Trioptic,UPC-A,UPC-E
Light levels (direct sunlight)	0 - 100000 lx
Tilt reading angle	10 - 47 °

Connectivity technology	Wireless
Standard interfaces	Bluetooth
Wireless range	10 m
Bluetooth version	2.1+EDR
Bluetooth	Yes

Product colour	Black,Green
Housing material	Plastic,Glass
International Protection (IP) code	IP67
Protection features	Drop resistant
LED indicators	Yes
Print contrast	25 %
Country of origin	China

Power source type	Battery
Battery technology	Lithium-Ion (Li-Ion)
Charging port type	USB Type-C
Battery capacity	700 mAh
Battery voltage	3.7 V
Number of reads per charge	500
Battery life	25 h
Charging time	8 h

Width	91 mm
Depth	91 mm
Height	193.1 mm

Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	0 - 60 %
Drop resistance	2.4 m
Operating relative humidity (H-H)	0 - 95 %
Operating temperature (T-T)	0 - 45 °C

Battery weight	12.5 g
Number of battery cells	1
Battery capacity	2.59 Wh
Rechargeable battery	Yes

Compliance certificates	RoHS,UKCA,Federal Communications Commission (FCC),CE
Warranty period	1 year(s)
