Produktbeskrivning

The XS640 stands out as a rugged, high-performance barcode scanner designed for fast, accurate 1D/2D scanning in demanding environments.

Based on the Socket Mobile XtremeScan Mag platform, the XS640 is designed for BYOD (Bring Your Own Device) operations and seamless integration with any mobile device. It offers an optimal solution to enhance efficiency and convenience in mobile workforces. Featuring a secure magnetic attachment system, workers can easily attach and detach their personal mobile devices throughout the day. This flexibility empowers users to switch between tasks such as navigation, photos, and communication while adding high-performance 1D/2D barcode scanning when needed.

With its innovative BYOD design and rugged durability, the XS640 is ideal for modern delivery and inventory operations. It ensures tasks are completed efficiently without requiring multiple devices.

Featuring a streamlined case format, the XS640 offers a compact, easy-to-handle design for comfortable use over long shifts. Its fast, omnidirectional 1D/2D scanning delivers effortless data capture, and the secure magnetic attachment system allows for quick access when scanning is required. With extended battery life, military-grade durability to withstand drops and harsh conditions, and intuitive LED indicators, the XS640 simplifies scanning tasks while maintaining performance in any work environment.

Equipped with Bluetooth connectivity and a strong metal plate attachment system, the XS640 ensures optimal compatibility with any mobile device and reliable integration with iOS and Android business applications.



Viktiga egenskaper

Socket Mobile XtremeScan Mag XS640. Type: Handheld bar code reader, Scanner type: 1D/2D, Sensor type: LED. Connectivity technology: Wireless, Standard interfaces: Bluetooth, Wireless range: 10 m. Product colour: Black, Green, International Protection (IP) code: IP67, Protection features: Drop resistant. Power source type: Battery, Battery technology: Lithium-Ion (Li-Ion), Battery capacity: 700 mAh. Width: 91 mm, Depth: 91 mm, Height: 193.1 mm



Teknisk specifikation

Type	Handheld bar code reader
Scanner type	1D/2D
2D (matrix & stacked) barcodes supported	Aztec Code,Composite Codes,Data Matrix,DotCode,Grid Matrix Code,Han Xin,MaxiCode,MicroPDF417,Micro QR Code,PDF417,QR Code
Linear (1D) barcodes supported	Codabar,Code 128,Code 93,Code 39,EAN-8,EAN-13,JAN-13,JAN-8,GS1 DataBar Expanded,GS1 DataBar Omnidirectional,GS1 Databar Limited,Interleaved 2 of 5,ISBT 128,Trioptic,UPC-A,UPC-E
Sensor type	LED
Light levels (direct sunlight)	0 - 100000 lx
Tilt reading angle	33.5 - 44.5 °

Connectivity technology	Wireless
Standard interfaces	Bluetooth
Wireless range	10 m
Bluetooth version	2.1+EDR
Bluetooth	Yes

Product colour	Black,Green
International Protection (IP) code	IP67
Protection features	Drop resistant
Print contrast	25 %
Country of origin	China

Power source type	Battery
Battery technology	Lithium-Ion (Li-Ion)
Battery capacity	700 mAh
Battery voltage	3.7 V
Number of reads per charge	500
Battery life	25 h
Charging time	8 h

Width	91 mm
Depth	91 mm
Height	193.1 mm

Storage relative humidity (H-H)	0 - 60 %
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Drop resistance	2.4 m
Operating relative humidity (H-H)	0 - 95 %

Rechargeable battery	Yes
Number of battery cells	1
Battery weight	12.5 g
Battery capacity	2.59 Wh

Compliance certificates	RoHS,UKCA,CE,Federal Communications Commission (FCC)
Warranty period	1 year(s)

Mobile operating systems supported	Android,iOS
Windows operating systems supported	Yes
