Produktbeskrivning

SonicWall Wireless Network Security solutions combine high-performance IEEE 802.11ac Wave 2 wireless technology with industry-leading next-generation firewalls. The result is a superior experience for Wi-Fi users that's as secure as any wired connection.



Egenskaper

Superior user experience
SonicWave APs take advantage of the capabilities in 802.11ac Wave 2 plus features such as band steering and a built-in 2.5 GbE port to deliver highspeed wireless performance. Other features, including 4x4 MU-MIMO and beamforming, improve performance in higher density environments when using bandwidth-intensive applications such as HD multimedia, and cloud and mobile apps. With four transmitting and four receiving antennas plus support for 4x4 MU-MIMO, SonicWave APs are engineered to optimize signal quality, range and reliability for wireless devices including Wave 2-enabled clients.

Comprehensive threat prevention
SonicWall firewalls scan all wireless traffic coming into and going out of the network using deep packet inspection technology and then remove harmful threats such as malware and intrusions, even over SSL/TLS encrypted connections. Other security and control capabilities such as content filtering, application control and intelligence and Capture Advanced Threat Protection provide added layers of protection. The Wireless Network Security solution also integrates additional security-related features including wireless intrusion detection and prevention, virtual access point segmentation, wireless guest services, RF monitoring and wireless packet capture.

Simplified deployment and centralized management
Access point deployment and setup are greatly simplified, reducing total cost of ownership (TCO). Integrated into every SonicWall firewall is a wireless controller that auto-detects and auto-provisions SonicWave APs across the network. Wireless signal analysis tools provide a visual map to optimize site-based access point placement. Management and monitoring for wireless and security are handled centrally through the firewall or through SonicWall Global Management System, providing network administrators with a single pane of glass from which to manage all aspects of the network.



Teknisk specifikation

Typ av enhet	Trådlös åtkomstpunkt
Servicepaket	1 års aktivering och 24x7-support
Robust design	Utomhus
Bredd	24.1 cm
Djup	23.6 cm
Höjd	6.1 cm
Vikt	2.2 kg
Lokalisering	Kanada

Formfaktor	Extern
Anslutningsteknik	Trådlös
Dataöverföringshastighet	1.7334 Gbps
Datalänkprotokoll	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
Metod för spridningsspektrum	OFDM, DSSS
Frekvensband	2.4 GHz, 5 GHz
Kapacitet	Virtuella åtkomstpunkter: 8 Maximalt antal klienter: 1024
Statusindikatorer	Strömförsörjning, testläge, WLAN, LAN
Funktioner	Automatisk avkänning per enhet, VPN-stöd, stöd för DFS, monterbar på vägg, Multipelt SSIUD-stöd, plenummärkt, takmonterbar, Captive Portal, Virtual Access Points (VAP), Reassembly-Free Deep Packet Inspection (RFDPI), 4x4 MU-MIMO-teknologi
Krypteringsalgoritm	AES, 128-bitars WEP, 64-bitars WEP, 152-bitars WEP, SSL, TKIP, WPA, WPA2
Verifieringsmetod	RADIUS, Active Directory
Standarder som följs	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11i, IEEE 802.11e, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac Wave 2, IEEE 802.3bz

Antenn	Extern löstagbar
Antal antenner	8

Gränssnitt	1 x 1/2.5GBase-T (PoE) - RJ-45 1 x 1000Base-T - RJ-45 1 x konsol - RJ-45

Inkluderade tillbehör	Monteringssats för vägg/tak
Standarder som följs	FCC Klass B-certifierade, UL, TUV GS, BSMI, cUL, CB, RoHS, ICES Class B, WEEE, ANATEL, TELEC, VCCI Class B, NCC, China RoHS, MSIP, CoC, ACMA RCM

Stöd för PoE (Power Over Ethernet)	PoE+
Nätdel	Strömtillförsel
Nätspänning	AC 120/230 V (50/60 Hz)
Energiförbrukning vid drift	21.2 Watt

Emballagets vikt	4.7 kg

Min temperatur vid drift	-40 °C
Max temperatur vid drift	60 °C
Luftfuktighet vid drift	10 - 95 % (icke-kondenserande)
