Produktbeskrivning

Incorporating a high quality thermal printing mechanism, the HSP7000 Series offers high performance print resolution and superior print speed creating the perfect POS printer for printing cheques and receipts.
Its high print resolution (203dpi) produces superior quality text and graphics for printing brand-enhancing logos, barcodes and promotional coupons or vouchers at the point of sale.
The HSP7000 is also incredibly easy to use with “Drop In & Print” loading of thermal receipt rolls as well as instant top of form positioning for fast, accurate cheque positioning. Ribbon replacement is simple and easily accessible and, as an extra measure, the HSP7000 includes cover open sensors and auto status back for paper loading to minimise down time.
Designed with the user in mind, the HSP7000 is simple to install and set-up with Star’s suite of drivers / emulation support and variable paper widths to match existing software.



Viktiga egenskaper

Star Micronics HSP7743-24. Print technology: Direct thermal, Type: POS printer, Maximum resolution: 203 x 203 DPI. Maximum roll diameter: 8.3 cm, Media thickness: 0.065 - 0.085 mm. Connectivity technology: Wired. Autocutter durability: 1.5 million cuts, Certification: UL, C-UL, TüV, FCC Class A, CE, CB GOST, C-tick, AS Standard, VCCI Class A, EN55022. Product colour: Grey



Teknisk specifikation

Print technology	Direct thermal
Type	POS printer
Colour	Yes
Maximum resolution	203 x 203 DPI
Print speed	250 mm/sec
Print speed	8.9 lps

Maximum roll diameter	83 mm
Media thickness	0.065 - 0.085 mm

Connectivity technology	Wired
Serial ports quantity	1

Ethernet LAN	No
Wi-Fi	No

Autocutter durability	1.5 million cuts
Certification	UL, C-UL, TüV, FCC Class A, CE, CB GOST, C-tick, AS Standard, VCCI Class A, EN55022

Product colour	Grey

Width	186 mm
Depth	296 mm
Height	177 mm
Weight	4600 g

Maximum print height	8 mm

Harmonized System (HS) code	84433210

Mean cycles between failures (MCBF)	60
