Produktbeskrivning

Avocent® Desktop KVM Switches simplify access to essential business systems.



Viktiga egenskaper

Vertiv Avocent SV Universal DP/H KVM Switch 16-Port Single Display. Keyboard port type: USB, Mouse port type: USB, Video port type: DisplayPort. HD type: 4K Ultra HD, Maximum resolution: 3840 x 2160 pixels. Product colour: Black, Rack capacity: 1U, Certification: CE, RCM, FCC class A, VCCI, TUV US, TUV Canada. Power source: AC, Input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Width: 348 mm, Depth: 127 mm, Height: 56 mm



Teknisk specifikation

Number of computers controlled	16
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
USB 2.0 Type-B ports quantity	4
Console USB ports quantity	3
USB connector type	USB Type-A,USB Type-B

HD type	4K Ultra HD
Maximum resolution	3840 x 2160 pixels

Rack capacity	1U
Rack mounting	No
Product colour	Black
LED indicators	Yes
Certification	CE, RCM, FCC class A, VCCI, TUV US, TUV Canada

Built-in display	No

Power source	AC
Input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Output voltage	12 V
Output current	2.5 A

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80 %

Width	348 mm
Depth	127 mm
Height	56 mm
Weight	1900 g
