Produktbeskrivning
The Cybex™ SC 800 series secure desktop KVM switching portfolio offers a proven solution for guarding against cyber intrusion at the desktop.
These switches are certified to meet the requirements of the latest NIAP Protection Profile for Peripheral Sharing Devices version 3.0. These switches provide users with high resolution compatibility utilizing HDMI and DisplayPort technology as well as traditional DVI technology.
Cybex secure KVM switches deliver strong, effective security management designed to prevent unauthorized access via peripheral devices while delivering transparent security that does not impede user productivity.
Viktiga egenskaper
Vertiv Avocent SC845D-202 KVM switch Black. Keyboard port type: USB, PS/2, Mouse port type: USB, PS/2, Video port type: HDMI/DisplayPort. HD type: 4K Ultra HD, Maximum resolution: 3840 x 2160 pixels, Number of users: 1 user(s). Product colour: Black, Housing material: Plastic, Steel, Certification: CE, RCM, FCC class B, VCCI, TUV US, TUV Canada. Power source: AC, Input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Width: 342 mm, Depth: 125 mm, Height: 42 mm
Teknisk specifikation
Ports & interfaces
| Number of computers controlled | 4 |
|---|
| Keyboard port type | USB, PS/2 |
|---|
| Mouse port type | USB, PS/2 |
|---|
| Video port type | HDMI/DisplayPort |
|---|
| HDMI ports quantity | 1 |
|---|
| DisplayPorts quantity | 4 |
|---|
| DisplayPort version | 1.2 |
|---|
| Console ports | 3.5mm headphone,DisplayPort,PS/2,USB A |
|---|
| Console USB ports quantity | 2 |
|---|
| USB connector type | USB Type-A,USB Type-B |
|---|
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
|---|
| PS/2 ports quantity | 2 |
|---|
| Audio connections | Yes |
|---|
| Headphone outputs | 5 |
|---|
Performance
| HD type | 4K Ultra HD |
|---|
| Maximum resolution | 3840 x 2160 pixels |
|---|
| Plug and Play | Yes |
|---|
| Number of users | 1 user(s) |
|---|
| Firmware upgradeable | No |
|---|
Design
| Rack mounting | Yes |
|---|
| Product colour | Black |
|---|
| Housing material | Plastic,Steel |
|---|
| LED indicators | Yes |
|---|
| Display switch button | Yes |
|---|
| Push button | Yes |
|---|
| Certification | CE, RCM, FCC class B, VCCI, TUV US, TUV Canada |
|---|
Display
| Built-in display | No |
|---|
Power
| Power source | AC |
|---|
| Input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Input current | 1.2 A |
|---|
| Power consumption (typical) | 35 W |
|---|
| Compatible power plug types | EU |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -20 - 60 °C |
|---|
| Operating relative humidity (H-H) | 0 - 80 % |
|---|
| Storage relative humidity (H-H) | 0 - 80 % |
|---|
Weight & dimensions
| Width | 342 mm |
|---|
| Depth | 125 mm |
|---|
| Height | 42 mm |
|---|
| Weight | 1600 g |
|---|
Packaging content
| Drivers included | No |
|---|
| Rack mount kit | No |
|---|
| Rubber feet | Yes |
|---|
| Software included | No |
|---|
| Manual | No |
|---|
| Quick installation guide | Yes |
|---|
