Produktbeskrivning

The Liebert® PSA is a compact line-interactive UPS that offers cost-effective, full featured power protection for small office computers and electronic equipment Designed with simple controls for easy operation, the Liebert PSA provides up to five minutes of back-up time at full load... more than enough time to save work in process and shut down your system. Shutdown software and a USB cable are also included, to allow remote alerts and automated graceful shutdown of the connected systems.



Viktiga egenskaper

Vertiv Liebert PSA 1000VA. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 600 W. AC outlet types: IEC 320, C13 coupler, Power plug: C14 coupler, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 7 VAh, Battery voltage: 12 V. Form factor: Tower, Product colour: Black, Cooling type: Passive. Compliance certificates: RoHS, Certification: CE



Teknisk specifikation

UPS topology	Line-Interactive
Output power capacity	1 kVA
Output power	600 W
Waveform	Stepwise
Input operation voltage (min)	160 V
Input operation voltage (max)	287 V
Input frequency	50/60 Hz
Response time	6 ms
Number of output phases	1
Power factor	0.6
Output power factor	0.6
Surge protection	Yes
Audible alarm(s)	Yes

AC outlet types	IEC 320,C13 coupler
Power plug	C14 coupler
AC outlets quantity	8 AC outlet(s)
USB port	Yes
USB 2.0 ports quantity	1
Serial ports quantity	1

Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	7 VAh
Battery voltage	12 V
Number of batteries supported	2
Typical backup time at full load	3 min
Typical backup time at half load	10 min
Battery recharge time	6 h

Form factor	Tower
Product colour	Black
Cooling type	Passive
LED indicators	Yes
International Protection (IP) code	IP20
Safety	IEC/EN/AS 62040-1-1
Certification	CE

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Storage relative humidity (H-H)	0 - 90 %
Operating altitude	0 - 3000 m

Compliance certificates	RoHS

Width	147 mm
Depth	360 mm
Height	234 mm
Weight	9500 g
Package width	238 mm
Package depth	432 mm
Package height	352 mm
Package weight	10700 g

Harmonized System (HS) code	85078000

Battery type	VRLA
Output connections	8 x IEC 320 C13
Dimensions (WxDxH)	147 x 360 x 234 mm
Nominal output voltage	230 V
