Produktbeskrivning
20xC13, 6xC19, 230V, 7.3 kW, 1683x51x51mm, 7.26kg
Viktiga egenskaper
Vertiv Geist GI30000L. PDU types: Monitored, Mounting: Vertical, Housing material: Steel. AC outlets quantity: 26 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC 60309. Cable length: 3 m. Monitoring: Current, Power, Voltage, Supported network protocols: DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+. Nominal input voltage: 220-240 V, Maximum current: 32 A, AC input frequency: 50 - 60 Hz
Teknisk specifikation
Design
| PDU types | Monitored |
|---|
| Mounting | Vertical |
|---|
| Housing material | Steel |
|---|
| Product colour | Black |
|---|
| Display | LED |
|---|
Ports & interfaces
| AC outlets quantity | 26 AC outlet(s) |
|---|
| Power plug | IEC 60309 |
|---|
| AC outlet types | C13 coupler,C19 coupler |
|---|
| Serial ports quantity | 2 |
|---|
| Ethernet LAN (RJ-45) ports | 2 |
|---|
Features
| Reset button | Yes |
|---|
| Daisy chain | Yes |
|---|
| Colour-coded outlets | Yes |
|---|
| Cable length | 3 m |
|---|
| Certification | CE, EN 55032,EN 55024, IEC 60950-1, RCM, UL, c-UL |
|---|
Management features
| Monitoring | Current,Power,Voltage |
|---|
| Supported network protocols | DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+ |
|---|
Power
| Nominal input voltage | 220-240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Maximum current | 32 A |
|---|
| Nominal output voltage | 230 V |
|---|
| Maximum power | 7300 W |
|---|
Weight & dimensions
| Width | 1683 mm |
|---|
| Depth | 51 mm |
|---|
| Height | 51 mm |
|---|
| Weight | 7260 g |
|---|
