Produktbeskrivning

Upgradeable Unit Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of input level power usage via remote network access. Includes environmental monitoring capabilities to obtain real-time environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.



Viktiga egenskaper

Vertiv Geist MG03E4B0-30PN63-2PS56B2A10-S-A-RC. PDU types: Monitored, Type: Three-phase, Mounting: Vertical. AC outlets quantity: 30 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC 60309. Cable length: 3 m. Monitoring: Current, Power, Voltage, Supported network protocols: DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog,.... Nominal input voltage: 200-240/346-415V WYE, Maximum current: 16 A, AC input frequency: 50/60 Hz



Teknisk specifikation

PDU types	Monitored
Type	Three-phase
Mounting	Vertical
Product colour	Black
Display	LED
On/off switch	No

AC outlets quantity	30 AC outlet(s)
Power plug	IEC 60309
AC outlet types	C13 coupler,C19 coupler
Serial ports quantity	1
Ethernet LAN (RJ-45) ports	1
USB ports quantity	1

Daisy chain	Yes
Reset button	Yes
LED indicators	Yes
Cable length	3 m
Certification	ANSI C12.1, IEC 62053-21, IEC 62368-1, EN 55032, EN 55035

Monitoring	Current,Power,Voltage
Supported network protocols	DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP

Nominal input voltage	200-240/346-415V WYE V
AC input frequency	50/60 Hz
Maximum current	16 A
Output voltage	230 V
Maximum power	11000 W
Circuit breaker	Yes

Width	51 mm
Depth	51 mm
Height	1683 mm

Package weight	6800 g

Operating temperature (T-T)	0 - 60 °C

Compliance certificates	CE,RoHS,UKCA
Warranty period	5 year(s)
Sustainability compliance	Yes
