Produktbeskrivning

WD Purple drives are designed to meet the challenges of 24 x 7 video surveillance recording. These drives are engineered specifically for surveillance to help withstand the elevated heat fluctuations and equipment vibrations within NVR environments. An average desktop drive is built to run for only short intervals, not the harsh 24/7 always-on environment of a high-definition surveillance system. With WD Purple drives, you get reliable, surveillance-class storage that's tested for compatibility in a wide range of security systems. Exclusive AllFrame technology helps reduce frame loss and improve overall video playback.



Egenskaper

Surveillance you can trust
Western Digital has provided surveillance-grade storage for more than a decade. With WD Purple surveillance storage, drives are engineered for high temperature, always-on surveillance systems so you can rely on quality video when you need it most. WD Purple delivers smart video storage that you can trust.

Western Digital's Exclusive AllFrame technology
All WD Purple drives are equipped with AllFrame technology, which helps reduce video frame drops and improves video recording and playback.

Enhanced workload ratings
WD Purple drives feature a workload rating of up to 180 TB/year - up to three times that of desktop drives - to handle the unique demands of mainstream video surveillance DVR and NVR systems.

Multiple cameras, multiple streams
Modern recorders now support multiple video streams per camera. WD Purple drives support up to 64 single-stream HD cameras. With so many options, you have the flexibility to upgrade or expand your security applications in the future.

Designed for surveillance solutions
With an MTBF of up to 1 million hours, WD Purple drives are engineered for mainstream surveillance DVRs and NVRs that operate 24/7. With tarnish-resistant components and support in storage systems with more than eight drive bays, WD Purple drives deliver reliable operation even in harsh environments.

Wide compatibility, seamless integration
WD Purple hard drives are built with compatibility in mind, so you can quickly and seamlessly add capacity to your surveillance system.



Teknisk specifikation

Typ av enhet	Hårddisk - inbyggd
Kapacitet	2 TB
Formfaktor	3.5"
Gränssnitt	SATA 6Gb/s
Buffertstorlek	64 MB
Egenskaper	Advanced Format-teknik, AllFrame, CMR (Conventional Magnetic Recording)
Bredd	101.6 mm
Djup	147 mm
Höjd	26.1 mm
Vikt	450 g

MTBF (genomsnittstid mellan fel)	1,000,000 timmar
Dygnet-runt drift	Ja
Oåterkalleligt fel	1 per 10^14
Ladda/ladda ur cykler	300,000

Gränssnitt	1 x SATA 6 Gb/s
Kompatibelt fack	3.5"

Strömkonsumtion	3.8 Watt (läs) 3.2 Watt (inaktiv) 0.3 Watt (viloläge)

Standarder som följs	RoHS

Service och support	Begränsad garanti - 3 år

Min temperatur vid drift	0 °C
Max temperatur vid drift	65 °C
Stöttolerans (vid drift)	30 g @ 2 ms
Stöttolerans (i vila)	250 g @ 2 ms
