Produktbeskrivning
As the industry evolves to develop purpose-built solutions for growing data storage requirements, IT managers continue to rely on lower capacity drives that are economical to acquire, yet deliver quick and reliable data access for traditional data center applications. Ultrastar DC HC310 is a low-capacity HDD, that helps address economic and access requirements of many traditional IT workloads. Low capacity drives also help address architecture limitations. Part of the mid-capacity DC HC300 series, the Ultrastar DC HC310 is designed for traditional storage and server applications as well as distributed and scalable computing, including block and file storage architectures, providing fast 7,200 RPM performance and lower acquisition cost to help ease budget constraints. Ultrastar DC HC310 is offered with SAS interface.
Egenskaper
Technology innovation delivers efficiency and performance for traditional and legacy systemsUltrastar DC HC310 is based on a 4-disk air platform design that uses conventional magnetic recording (CMR) technology in a 3.5-inch large form factor. Compared to the prior generation, Ultrastar 7K6000, the DC HC310 delivers a 12% performance boost and uses slightly larger-diameter media. It features a second-generation, dual-stage micro actuator to enhance head positioning accuracy for better drive performance. Write performance gains are also supported by Western Digital's media cache architecture, a disk-based caching technology that provides a large cache area on the disk, which also improves reliability and data integrity during unexpected power loss. Finally, the addition of flash-based non-volatile cache (NVC) on both SATA and SAS models helps improve write performance. The Ultrastar DC HC310 also includes a Rebuild Assist feature, which helps dramatically reduce RAID rebuild times and maintain system performance during the rebuild process.
Data security with trusted quality, reliabilityCompliance and privacy requirements drive the need for increased data security. Ultrastar DC HC310 helps protect data from unauthorized use by offering security and encryption options. SAS models offer hardware-based encryption options, including a Trusted Computing Group (TCG) Enterprise A, TCG with FIPS 140 - 2 certification, Level 2.
Teknisk specifikation
Allmänt
Typ av enhet | Hårddisk - inbyggd |
Kapacitet | 8 TB |
Formfaktor | 3.5" |
Gränssnitt | SATA 6Gb/s |
Buffertstorlek | 256 MB |
Byte per sektor | 512 |
Egenskaper | Dual Stage Actuator (DSA), Säker raderingsfunktion, HelioSeal, 24x7 kontinuerlig drift, Enhanced Rotational Vibration Safeguard (RVS), avancerat format 512e, Dynamic fly height-teknologi |
Bredd | 101.6 mm |
Djup | 147 mm |
Höjd | 26.1 mm |
Vikt | 650 g |
Prestanda
Hårddiskens överföringshastighet | 600 MBps (extern) |
Intern datafrekvens | 205 MBps |
Söktid | 8 ms (medel) / 8.6 ms (max) |
Genomsnittlig åtkomsttid | 4.16 ms |
Spindelhastighet | 7200 rpm |
Pålitlighet
MTBF (genomsnittstid mellan fel) | 2,000,000 timmar |
Dygnet-runt drift | Ja |
Oåterkalleligt fel | 1 per 10^15 |
Ladda/ladda ur cykler | 600,000 |
Expansion och anslutningar
Gränssnitt | 1 x SATA 6 Gb/s |
Kompatibelt fack | 3.5" |
Strömtillförsel
Strömkonsumtion | 8.8 Watt (aktiv) 7.4 Watt (inaktiv) |
Diverse
Standarder som följs | RoHS 2011/65/EU |
Tillverkarens garanti
Service och support | Begränsad garanti - 5 år |
Miljöparametrar
Min temperatur vid drift | 5 °C |
Max temperatur vid drift | 60 °C |
Min temperatur vid förvaring | -40 °C |
Max temperatur vid förvaring | 70 °C |
Stöttolerans (vid drift) | 70 g @ 2 ms halvsinusvåg |
Stöttolerans (i vila) | 300 g @ 2 ms halvsinusvåg |
Vibrationstolerans (vid drift) | 0.67 g @ 5-500 Hz |
Vibrationstolerans (i vila) | 1.04 g @ 2-200 Hz |
