Produktbeskrivning

Zebra ET51, kit, 2D, SE4710, USB, BT, Wi-Fi, NFC, GPS



Viktiga egenskaper

Zebra ET51. Display diagonal: 25.6 cm (10.1"), Display resolution: 2560 x 1600 pixels. Internal storage capacity: 64 GB. Processor frequency: 1.6 GHz, Processor family: Intel Atom®, Processor model: x5-E3940. Internal memory: 4 GB. Rear camera resolution (numeric): 8 MP, Rear camera type: Single camera, Front camera resolution (numeric): 2 MP, Front camera. Top Wi-Fi standard: 802.11b. Weight: 765 g. Operating system installed: Windows 10 IoT Enterprise. Product colour: Black



Teknisk specifikation

Display diagonal	10.1 "
Display resolution	2560 x 1600 pixels
Touchscreen type	Capacitive
HD type	Full HD

Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	x5-E3940
Processor cores	4
Processor threads	4
Processor boost frequency	1.8 GHz
Processor frequency	1.6 GHz
Processor cache	2 MB
Processor cache type	L2
Processor package size	24 x 31 mm
Conflict-Free processor	Yes
UART	Yes
Thermal Monitoring Technologies	Yes
Thermal Design Power (TDP)	9.5 W
Processor lithography	14 nm
Tjunction	110 °C
Tcase	100 °C
Processor operating modes	64-bit
Number of execution units	12
Processor series	Intel Atom x5 Series
Processor codename	Apollo Lake

Internal memory	4 GB
Internal memory type	DDR4-SDRAM

Internal storage capacity	64 GB
Compatible memory cards	MMC

Rear camera type	Single camera
Rear camera resolution (numeric)	8 MP
Front camera	Yes
Front camera resolution (numeric)	2 MP

Mobile network connection	Yes
Mobile network generation	4G
4G standard	LTE
Bluetooth	Yes
Bluetooth version	4.2
Top Wi-Fi standard	802.11b
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n)
Near Field Communication (NFC)	Yes

Form factor	Slate
Product colour	Black
Device type	Tablet PC
International Protection (IP) code	IP65

Position location	Yes
GLONASS	Yes
GPS (satellite)	Yes
Galileo	Yes

Platform	Windows
Operating system installed	Windows 10 IoT Enterprise

Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel® High Definition Audio (Intel® HD Audio)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Secure Key	Yes
Intel Secure Boot	Yes
Embedded options available	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel 64	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Physical Address Extension (PAE)	Yes
Intel Trusted Execution Technology	No
Execute Disable Bit	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® OS Guard	No
Intel Rapid Storage Technology	No
Intel® Smart Response Technology	No
Intel Smart Connect Technology	No
Intel Stable Image Platform Program (SIPP)	No
Intel Clear Video Technology	Yes
Physical Address Extension (PAE)	40 bit
Intel® Turbo Boost Technology	No

Battery technology	Lithium-Ion (Li-Ion)
Battery capacity	4950 mAh
Battery capacity	38 Wh
Battery voltage	3.6 V

Width	228 mm
Depth	12.7 mm
Height	150 mm
Weight	765 g

Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-20 - 60 °C

Harmonized System (HS) code	84713000

Processor ARK ID	96485
