Produktbeskrivning

The AN610 is space-saving and stylish. The outer housing is designed to be sleek and discreet enough to be at home in any business setting but rugged enough for indoor industrial environments.

Easy to Mount
The AN610 features a simple, integrated mounting system. It stands just under one-half inch (12mm) from horizontal or vertical mounting surfaces.

Stylish Space Saver
The outer shell is sleek and discreet for any business setting but rugged enough for indoor industrial areas.

Suited For All Areas
The AN610 antenna is suited for use in wall mount, doorways, under counter, above counter as an RFID pad, on shelves, POS or end-cap displays like jewelry counter applications.



Viktiga egenskaper

Zebra AN610. Antenna gain level (max): 1 dBi, Frequency band: 0.864 - 0.868 GHz. Antenna type: Omni-directional antenna, Antenna connector type: N-type, Connector gender: Female. Power consumption (max): 6 W. Width: 214 mm, Depth: 12 mm, Height: 275 mm. Quantity per pack: 1 pc(s)



Teknisk specifikation

Antenna gain level (max)	1 dBi
Frequency band	0.864 - 0.868 GHz

Antenna type	Omni-directional antenna
Connector gender	Female
Antenna connector type	N-type
Polarization	Circular polarization
Voltage Standing Wave Ratio (VSWR)	1.4:1
Mounting	Ceiling/wall
Purpose	Indoor & outdoor
Front to back ratio	18 dB
Isolation	38 dB
Product colour	Black

Power consumption (max)	6 W

Operating temperature (T-T)	-30 - 65 °C
Storage temperature (T-T)	-40 - 70 °C

Width	214 mm
Depth	12 mm
Height	275 mm
Weight	600 g

Quantity per pack	1 pc(s)

Harmonized System (HS) code	85177100
